Pixel Pitch
18.75mm
Pixel Density
2,844dots/m2
Pixel Configuration
1R1G1B
LED Type
SMD5050
Module Size
600mm×600mm×91m
Unit Module Size
150mm×600mm
Unit Module Resolution
8 dots×32 dots
Cabinet Weight
7.6KG
Power (max)
200W/set
Display Brightness
5000cd/m2
Gray Scale
RGB12bit
IP Rating
IP65
Viewing Angle
Horizontal 140 degrees
Vertical 140 degrees
Luminous Flux
30%
Drive Mode
Static constant current driver
Refresh Rate
1500HZ
Display Life
>50000H
Working Voltage
AC220V/50HZ;AC110V/60HZ
Operation Temperature
-20°C~+60°C
Operation Humidity
10%~90%
Tube Chip Parameter
Item
Wavelength
Brightness
Red tube chip
625nm
400-450mcd
Pure green tube chip
515-520nm
1900-2400mcd
Pure blue tube chip
465nm
300-400mcd
